Best Flake Ice Machines 2026: Commercial Flake Ice Makers for Australian Seafood, Medical & Industrial

The Coast Team on 20th Jan 2026

Flake ice is the workhorse of professional food presentation, seafood operations, medical applications, and industrial cooling. Its soft, dry, subcooled properties make it irreplaceable for specific commercial applications where cube ice simply cannot perform-from Sydney Fish Market displays to concrete plants managing pour temperatures in Australian summers.

This comprehensive guide covers the best flake ice machines available for Australian businesses in 2026, from self-contained commercial units producing 200-300kg daily to industrial systems generating tonnes for large-scale operations. We'll review Grant Sub Zero, Ice-O-Matic, and Follett offerings to help you select the right flake ice maker for your specific application.

Need help sizing your flake ice system?
Get expert recommendations → or call 1800 688 590 for immediate assistance.

What is Flake Ice? Understanding the Production Process

Flake ice differs fundamentally from cube ice in both production and properties. Understanding these differences explains why certain applications demand flake ice exclusively.

How Flake Ice Forms

Flake ice production uses a cylindrical evaporator system:

  1. Water enters the cylindrical evaporator chamber
  2. Refrigerant chills the inner drum wall to sub-zero temperatures
  3. Water freezes on the drum surface in a thin layer
  4. Rotating auger or scraper continuously removes ice as thin flakes
  5. Flakes fall into storage bin below through gravity
  6. Process repeats continuously for consistent production

Unlike cube ice makers that operate in batch cycles (freeze, harvest, repeat), flake ice machines produce continuously. This continuous process typically delivers ice faster per kg than equivalent cube makers.

Key Characteristics of Quality Flake Ice

Subcooled temperature: Quality flake ice exits machines below 0°C-colder than standard cube ice. This subcooling provides additional cooling capacity and extends storage life. Exact temperatures vary by manufacturer and conditions.

Soft, moldable texture: Flake ice conforms to product surfaces without causing damage. This property makes it essential for seafood display where crushing or puncturing delicate fish flesh would be unacceptable.

Lower density than solid ice: A portion of flake ice volume is air and residual water, creating the soft texture while still providing substantial cooling mass.

No sharp edges: Unlike cube ice with hard corners and edges, flake ice is gentle on products, workers' hands, and equipment.

Rapid heat absorption: The thin flake structure maximises surface area contact, enabling faster heat transfer from products to ice compared to solid cubes.

Wet Flake vs Dry Flake: Quality Matters

Not all flake ice is equal. Production method and machine quality determine whether you get professional-grade dry flake or lower-quality wet flake:

Wet flake ice:

  • Higher water content
  • Softer, mushier texture
  • Less subcooling
  • Clumps together easily
  • Shorter storage life
  • Common in entry-level machines

Dry flake ice (professional standard):

  • Lower water content
  • Harder, drier texture
  • More subcooled
  • Resists clumping in storage
  • Longer storage life
  • Standard from quality manufacturers like Grant Sub Zero

For professional seafood, medical, and food processing applications, dry subcooled flake ice is the required standard. Equipment selection should prioritise dry flake production.

Who Uses Flake Ice? Commercial and Industrial Applications

Seafood and Fish Markets: The Primary Market

Flake ice is mandatory for professional seafood operations. No alternative exists that provides the same combination of properties:

Temperature control: Subcooled flake ice at -7°C keeps fish at safe temperatures (0-4°C) significantly longer than cube ice at 0°C. The temperature buffer protects product quality during display.

Product protection: Soft flake ice conforms to fish bodies without puncturing skin, crushing delicate flesh, or creating pressure marks that reduce sale value.

Visual presentation: Flake ice creates attractive, professional display beds that showcase seafood effectively. Customers associate flake ice displays with quality.

Coverage and conformity: Unlike cubes that leave air gaps, flake ice fills spaces and maintains contact across product surfaces for consistent cooling.

Typical seafood requirements (projected estimates):

  • Small fishmonger counter: ~30-80kg daily
  • Medium fish market stand: ~100-200kg daily
  • Large wholesale operation: ~300-600kg daily
  • Major fish market: ~1,000kg+ daily

Actual requirements vary by display size, product volume, ambient conditions, and operational patterns.

Supermarket Fresh Sections

Fresh food departments rely on flake ice for multiple applications:

Seafood counters: Same requirements as standalone fish markets-professional presentation with consistent cooling.

Produce displays: Vegetables, particularly leafy greens, benefit from flake ice beds maintaining crispness and visual appeal.

Butcher counters: While less common than seafood use, some operations use flake ice for display cooling and temperature control during high-volume periods.

Deli sections: Prepared foods, salads, and display items use flake ice beds for temperature maintenance during service.

Major supermarket chains typically centralise flake ice production, transporting ice to display counters throughout stores. This approach reduces equipment count while ensuring consistent quality across departments.

Healthcare and Medical Applications

Flake ice serves multiple medical purposes:

Therapeutic ice packs: Soft flake ice moulds easily into cold packs and compresses, conforming to body contours without causing tissue damage from hard edges.

Pathology transport: Sample transport requires precise temperature control. Flake ice provides consistent cooling with predictable melt rates.

Organ preservation: Critical medical applications rely on flake ice for temperature-controlled transport and storage.

Patient cooling: Fever management and post-operative cooling use flake ice for controlled temperature reduction.

Laboratory applications: Scientific research requires precise temperature control. Flake ice provides consistent, predictable cooling for specimen preservation and experimental temperature management.

Food Processing and Manufacturing

Food processors use flake ice for temperature control during production:

Bakeries: Dough mixing generates heat through friction. Adding flake ice controls dough temperature during mixing-critical for gluten development and fermentation management. Commercial bakeries commonly add ice during mixing, with amounts varying by recipe and ambient conditions.

Meat processing: Temperature management during grinding, mixing, and portioning prevents bacterial growth and maintains product quality. Flake ice integrates directly into mixes or provides indirect cooling.

Poultry processing: Carcass cooling, transport, and processing temperature control rely heavily on flake ice in commercial poultry operations.

Seafood processing: Beyond display, processing operations use flake ice for filleting stations, packing, and transport cooling.

Chemical processing: Some industrial processes require precise temperature control during reactions. Flake ice provides consistent, measurable cooling input.

Concrete Industry: Industrial-Scale Application

Perhaps the largest-volume flake ice application is concrete cooling:

Why concrete needs cooling: Concrete generates heat during curing (hydration). In hot Australian climates, uncontrolled curing temperatures cause:

  • Thermal cracking from temperature differentials
  • Reduced ultimate strength
  • Poor workability during placement
  • Accelerated setting times causing placement problems

How flake ice helps: Adding flake ice directly to concrete mixes replaces mixing water. The subcooled ice (-7°C) provides massive cooling capacity as it melts to water (0°C), then warms to ambient temperature. This keeps concrete temperature within specified limits (typically below 32°C at placement).

Typical concrete plant requirements (projected estimates):

  • Small batch plant: ~1,000-2,000kg daily
  • Medium commercial plant: ~3,000-5,000kg daily
  • Large infrastructure project: ~5,000-10,000kg+ daily

Actual requirements depend on pour volume, ambient temperatures, and specification requirements. Industrial flake ice systems producing multi-tonne quantities daily serve major concrete operations during Australian summers.

Best Flake Ice Machines Compared: 2026 Models

Pricing is indicative and subject to change. Contact Coast Distributors for current pricing and availability.

Machine Daily Output Storage Type Best For Price Range
Grant PB0.3F-FZ/Y 300kg 150kg Self-Contained Seafood, supermarkets $10,000-14,000
Grant MB0.3F-FZ/Y 300kg - Modular Flexible installations $8,000-11,000
Follett MFE414ABT 193kg - Modular Hospitality, healthcare $7,000-9,000
Ice-O-Matic MFI0805A 333kg - Modular Medium commercial $9,000-12,000
Ice-O-Matic MFI1255A 572kg - Modular High-volume operations $14,000-18,000
Grant FF0.4AR 400kg - Industrial Processing facilities $12,000-16,000
Staff SPS950 950kg - Industrial High-capacity operations $18,000-24,000
Hoshizaki FM-480AKE 425kg - Modular High-volume commercial $18,000-24,000
Hoshizaki FM-600AKE 530kg - Modular High-volume commercial $22,000-28,000

Top Flake Ice Machines Reviewed: Detailed Analysis

Best Self-Contained Commercial: Grant Sub Zero PB0.3F-FZ/Y

Full Specifications:

  • Daily production: 300kg (at 25°C ambient, 16°C water)
  • Storage capacity: 150kg integrated bin
  • Dimensions: 1120W x 675D x 1985H mm
  • Ice type: Dry subcooled flake (-7°C)
  • Electrical: 240V/15A single phase
  • Refrigerant: R404A
  • Construction: 304 stainless steel evaporators and surrounds
  • Warranty: 3 years parts & labour, 5 years evaporator

The Grant Sub Zero PB0.3F-FZ/Y is the go-to choice for Australian seafood operations. At 300kg daily production with 150kg integrated storage, it handles medium-commercial seafood operations, supermarket displays, and food processing applications without requiring separate bin purchase.

Why It's Our Top Self-Contained Pick:

The self-contained design integrates production and storage in a single floor-standing unit. This simplifies installation-connect power, water, and drain, and you're operational. No separate bin specification, no stacking considerations, no complex configuration decisions.

Grant's D-shaped stainless steel coil design delivers energy-efficient ice production. The unique coil geometry maximises heat transfer efficiency while maintaining the subcooled dry flake quality that professional operations require.

Australian Climate Engineering:

Grant specifically engineers for Australian conditions. The PB0.3F-FZ/Y operates effectively at ambient temperatures up to 35°C-critical for operations without climate-controlled back-of-house areas. Many imported machines underperform or fail in Australian summer conditions.

Professional Ice Quality:

The 300kg daily production delivers professional-grade dry subcooled flake at -7°C. This ice quality exceeds most competitor offerings, providing longer storage life and better cooling performance than wet flake alternatives.

Storage Integration:

The 150kg integrated bin provides substantial buffer capacity-12 hours of production stored and ready. This handles peak demand periods without production catching up after depletion.

Installation Considerations:

  • Floor space: 1120mm x 675mm footprint
  • Height: 1985mm requires adequate ceiling clearance
  • Weight: 300kg+ when fully loaded-verify floor capacity
  • Ventilation: Adequate airflow required (air-cooled)
  • Drainage: Continuous operation requires reliable drain

Best for: Fish markets, butchers, supermarket seafood counters, food processors, meat and poultry operations, medium-scale commercial applications

Interested in the PB0.3F-FZ/Y? Request a quote → or view full specifications →

Best Modular Configuration: Grant MB0.3F-FZ/Y

Full Specifications:

  • Daily production: 300kg
  • Type: Modular head (requires separate bin)
  • Ice type: Dry subcooled flake
  • Electrical: 240V/15A single phase
  • Refrigerant: R404A
  • Construction: 304 stainless steel
  • Warranty: 3 years parts & labour, 5 years evaporator

The Grant MB0.3F-FZ/Y delivers identical 300kg daily production and ice quality as the self-contained PB model, but in modular configuration. The ice maker head mounts on a separate storage bin, providing flexibility the integrated unit cannot offer.

When Modular Makes Sense:

Variable storage needs: Different operations need different bin sizes. Modular configuration lets you pair the 300kg head with bins from 150kg to 500kg+ depending on your storage requirements.

Service accessibility: Modular installations often provide easier service access than integrated units. The separate bin and head can be serviced independently.

Space constraints: Some installations fit a wide bin with short head better than a tall integrated unit. Modular configuration adapts to physical constraints.

Future scalability: As operations grow, you can upgrade bin size without replacing the ice maker head. The same head serves expanding storage needs.

Bin Pairing Options:

Grant offers multiple bin sizes for modular flake makers:

  • Small bins (150-200kg): Compact installations
  • Medium bins (250-350kg): Standard commercial
  • Large bins (400-500kg+): High-volume buffering

Match bin capacity to peak demand periods. Larger bins cost more but provide operational buffer during rush periods.

Best for: Custom installations, operations needing scalability, sites with specific space constraints, operations prioritising service accessibility

Interested in the MB0.3F-FZ/Y? Request a quote → or view full specifications →

Best for Hospitality: Follett MFE414ABT (Maestro Plus Flake)

Full Specifications:

  • Daily production: 193kg (at 21°C ambient/15°C water)
  • Type: Modular top-mount
  • Ice type: Flake
  • Platform: Maestro Plus
  • Electrical: 230V/50Hz
  • Refrigerant: R404A
  • Warranty: 3 years parts & labour, 5 years compressor

The Follett MFE414ABT brings Follett's proven Maestro platform to flake ice production. At 193kg daily, it suits hospitality and healthcare operations needing professional flake ice at moderate volumes without industrial-scale equipment.

Maestro Platform Advantages:

Built on the same platform as Follett's acclaimed chewblet/nugget machines, the MFE414ABT inherits:

Energy efficiency: Manufacturer reports indicate significant energy savings versus comparable ice makers. The Maestro platform specifically targets operational cost reduction.

Water efficiency: Manufacturer claims substantial annual water savings compared to conventional machines, providing operational cost benefit.

Quiet operation: Hospital-grade noise levels suit front-of-house or patient-adjacent installations where noise matters.

European design: Compact, professional appearance appropriate for visible installations.

Hospitality Applications:

Hotel kitchens: Room service, banquet preparation, and restaurant operations use flake ice for food presentation and temperature control.

Restaurant back-of-house: Seafood restaurants, oyster bars, and any operation serving fresh seafood need flake ice for display and prep station cooling.

Catering operations: Mobile and fixed catering facilities use flake ice for transport, display, and temperature maintenance during events.

Healthcare crossover: Hospitals, aged care facilities, and medical operations needing flake ice for therapeutic or laboratory use find the Maestro platform's quiet operation and reliability appropriate.

Production Reality:

193kg daily equals roughly 8kg per hour continuous production. For a restaurant seafood display requiring 50kg morning refresh plus 30kg midday top-up, the MFE414ABT handles requirements with comfortable margin.

Best for: Hotels, restaurants, healthcare facilities, catering operations, moderate-volume commercial applications where energy efficiency and quiet operation matter

Interested in the MFE414ABT? Request a quote → or view full specifications →

Best Mid-Range Commercial: Ice-O-Matic MFI0805A

Full Specifications:

  • Daily production: 333kg (at 21°C ambient/15°C water)
  • Type: Modular ice head
  • Ice type: Granular flake
  • Electrical: 240V/15A single phase
  • Refrigerant: R404A
  • Warranty: 3 years parts & labour, 5 years evaporator & compressor

The Ice-O-Matic MFI0805A delivers over 330kg of granular flake ice daily-substantial commercial capacity from a proven manufacturer. Ice-O-Matic's flake series brings the same reliability and value as their market-leading cube ice lines.

Ice-O-Matic Reliability:

Ice-O-Matic has established Australian market presence through consistent quality and service support. The MFI series brings this reputation to flake ice:

Extended warranty coverage: The 5-year evaporator and compressor warranty exceeds industry standards, reflecting manufacturer confidence in core components.

Service network: Ice-O-Matic's Australian service network ensures parts availability and technical support.

Proven platform: The MFI series uses proven refrigeration and control systems from Ice-O-Matic's broader commercial lineup.

Commercial Capacity:

333kg daily production handles substantial commercial requirements:

  • Large supermarket seafood counter: 100-150kg daily
  • Medium fish market operation: 150-250kg daily
  • Food processing facility: 200-300kg daily

The MFI0805A provides comfortable headroom for these applications with production buffer for peak periods.

Modular Flexibility:

As a modular head, the MFI0805A pairs with Ice-O-Matic's bin range:

  • B40 bin: 156kg storage
  • B55 bin: 232kg storage
  • Larger bins for higher storage requirements

Select bin capacity based on peak demand patterns and production buffer needs.

Best for: Medium seafood operations, food processors, supermarket applications, operations valuing Ice-O-Matic reliability and warranty coverage

Interested in the MFI0805A? Request a quote → or view full specifications →

Best High-Volume Commercial: Ice-O-Matic MFI1255A

Full Specifications:

  • Daily production: 572kg (at 21°C ambient/15°C water)
  • Type: Modular ice head
  • Ice type: Granular flake
  • Electrical: 240V/20A single phase
  • Refrigerant: R404A
  • Warranty: 3 years parts & labour, 5 years evaporator & compressor

For operations needing over half a tonne of flake ice daily, the Ice-O-Matic MFI1255A delivers. At 572kg production, it suits large seafood markets, food processing facilities, and high-volume commercial applications.

High-Volume Capacity:

572kg daily equals approximately 24kg per hour continuous production. This capacity serves:

  • Large fish market operations: 300-500kg daily with buffer
  • Food processing plants: High-volume temperature control
  • Central ice production: Supplying multiple downstream users
  • Industrial food operations: Meat, poultry, and seafood processing

Built for Continuous Operation:

High-volume applications demand equipment designed for continuous duty:

Robust construction: Commercial-grade components handle sustained operation without premature wear.

Thermal management: Adequate refrigeration capacity maintains ice quality during extended production runs.

Service accessibility: Design accommodates routine maintenance without extended downtime.

Extended Warranty Value:

The 5-year evaporator and compressor warranty provides genuine value for high-volume operations:

At 572kg daily (208 tonnes annually), component failures cause significant operational disruption. Extended warranty coverage protects against major repair costs during the critical first five years.

Bin Selection:

High production requires adequate storage:

  • B55 bin: 232kg (insufficient for this production level)
  • B110 bin: 388kg (better match)
  • Large custom bins: 500kg+ for maximum buffering

Match storage to peak consumption patterns. Operations consuming ice throughout the day need less storage than operations loading displays in concentrated periods.

Best for: Large fish markets, food processing plants, industrial food operations, high-volume commercial applications

Interested in the MFI1255A? Request a quote → or view full specifications →

Industrial Range: Grant FF-AR Series

For operations requiring 400kg to 10,000kg daily, Grant's FF-AR series delivers industrial-scale flake ice production with integrated refrigeration:

Model Daily Output Type Best For
FF0.4AR 400kg With refrigeration Small processing
FF0.6AR 600kg With refrigeration Medium processing
FF1AR 1,000kg With refrigeration Large processing
FF1.5AR 1,500kg With refrigeration Major facilities
FF2AR 2,000kg With refrigeration Industrial
FF2.5AR 2,500kg With refrigeration Large industrial
FF3AR 3,000kg With refrigeration Heavy industrial
FF5AS 5,000kg Special Major operations
FF10AS 10,000kg Special Maximum capacity

Industrial Design Features:

Complete refrigeration systems: AR series includes integrated refrigeration-no external refrigeration plant required. Connect power, water, and drain for operational systems.

Sub Zero flake quality: Industrial volumes maintain the same dry subcooled flake quality as commercial units. Quality doesn't compromise with scale.

Stainless steel construction: Industrial environments demand corrosion resistance. All Grant FF series feature stainless steel covers and food-contact surfaces.

Scalable capacity: Operations can start with 400kg units and scale to multi-tonne systems as requirements grow. Component standardisation supports this scaling.

Industrial Applications:

Concrete plants: 1,000-10,000kg daily for mix temperature control Fish processing: 500-5,000kg daily for processing line cooling Meat processing: 500-3,000kg daily for temperature management Major supermarket chains: 1,000-3,000kg daily for centralised production

Installation Considerations:

Industrial flake systems require:

  • Three-phase electrical supply (larger models)
  • Substantial water supply capacity
  • Floor drainage handling significant melt water
  • Structural floor capacity (systems weight 500kg-2,000kg+)
  • Adequate ventilation (air-cooled) or water cooling

Best for: Concrete plants, large food processors, industrial fishing operations, major supermarket chains, any operation requiring 400kg+ daily

Industrial Evaporator Series: Grant FF-E and Staff SPS

For operations with existing central refrigeration systems, evaporator-only units provide cost-effective ice production:

Grant FF-E Series:

Model Daily Output
FF0.4E 400kg
FF0.6E 600kg
FF1E 1,000kg
FF2E 2,000kg
FF3E 3,000kg
FF5E 5,000kg

Staff SPS Series:

Model Daily Output
SPS950 950kg
SPS1300 1,300kg
SPS2000 2,000kg
SPS3000 3,000kg

Evaporator-Only Advantages:

Lower capital cost: Without integrated refrigeration, evaporator-only units cost 30-50% less than complete systems.

Central refrigeration efficiency: Facilities with existing refrigeration plants can leverage that investment rather than duplicating compressors.

Shipboard applications: Marine vessels with central refrigeration add flake ice production through evaporator units.

Industrial integration: Large processing facilities integrate evaporator units into existing refrigeration infrastructure.

Staff SPS Features:

Staff industrial evaporators feature:

  • Stainless steel drum construction
  • High-efficiency auger design
  • Continuous production capability
  • Compatible with standard refrigerants
  • Robust bearing systems for extended service life

Best for: Shipboard applications, facilities with central refrigeration, industrial installations, operations prioritising capital cost efficiency

Other Flake Ice Brands

Hoshizaki FM Series

Hoshizaki produces flake ice through their FM series.

Specifications (FM-480AKE):

  • Daily production: 425kg at 21°C/15°C (325kg at AHRI conditions)
  • Dimensions: 560W x 700D x 780H mm
  • Refrigerant: R404A (R290 on HC model)

Specifications (FM-600AKE):

  • Daily production: 400-530kg (depending on conditions)
  • Dimensions: 560W x 700D x 780H mm
  • Electrical: 1.95kW, 220-240V/50Hz

Considerations for Australian buyers: Hoshizaki products are typically positioned at premium price points and are not distributed through Coast Distributors. Service and parts availability may vary by location-worth confirming with local technicians before purchase.

Scotsman Flake Ice

Scotsman offers European-engineered flake systems through their AF series and Prodigy platform. Production ranges from approximately 100kg daily (AF103) to 200kg daily (AF206).

Considerations for Australian buyers: Like Hoshizaki, Scotsman products are typically positioned at premium price points and have a smaller Australian service network than Ice-O-Matic or Grant Sub Zero.

Why We Focus on Grant Sub Zero and Ice-O-Matic

Coast Distributors is Australia's exclusive importer of Grant Sub Zero and Ice-O-Matic, and specialises in these products because we can fully support them across Australia-from sizing consultation through installation, warranty service, and ongoing maintenance. We stock parts, train technicians, and stand behind every machine we sell. Grant Sub Zero flake ice machines are specifically engineered for Australian conditions, with subcooled dry flake production optimised for seafood and food processing applications.

Flake Ice vs Other Ice Types: Application Comparison

Application Flake Full Cube Half Cube Nugget
Seafood display Excellent Poor Poor Poor
Produce beds Excellent Poor Poor Fair
Drinks Poor Excellent Excellent Excellent
Blending Good Poor Poor Excellent
Medical/therapeutic Excellent Fair Fair Good
Concrete cooling Excellent No No No
Food processing Excellent Fair Fair Fair
Visual presentation Excellent Fair Fair Poor
Storage life Good Excellent Excellent Moderate
Cost per kg Moderate Moderate Moderate Higher

When Flake Ice is Essential

Seafood operations: No acceptable alternative. Cube ice damages product; nugget ice doesn't provide proper bed structure.

Food display requiring product contact: Only flake ice provides soft, conforming contact without damage risk.

Food processing temperature control: Rapid heat absorption and integration into mixes requires flake ice characteristics.

Concrete cooling: Only flake ice dissolves into concrete mix effectively while providing sufficient cooling capacity.

When Flake Ice is Unnecessary

Beverage service: Flake ice melts too rapidly and over-dilutes drinks. Use cube or nugget ice.

Self-serve dispensing: Flake ice clumps and doesn't dispense reliably. Use cube or nugget ice.

General commercial where cube suffices: If presentation and product contact aren't critical, cube ice costs less to produce.

Sizing Your Flake Ice Machine

Seafood Display Sizing

Display Configuration Ice Required Recommended Machine
Small counter (1m) 30-50kg/day Follett MFE414ABT (193kg)
Medium display (2m) 60-100kg/day Grant PB0.3F-FZ/Y (300kg)
Large display (3m+) 100-200kg/day Ice-O-Matic MFI0805A (333kg)
Fish market stand 200-400kg/day Ice-O-Matic MFI1255A (572kg)
Large fish market 400-800kg/day Grant FF1AR (1,000kg)

Food Processing Sizing

General guideline: 0.5-1.0kg of flake ice per kg of product for temperature control applications.

Bakery dough mixing: 10-20% of flour weight as ice for temperature control.

Meat processing: 15-25% by weight for grinding and mixing operations.

Calculate based on:

  • Daily production volume (kg)
  • Temperature reduction required (°C drop)
  • Processing time constraints
  • Ambient temperature conditions

Buffer Capacity Planning

Always size 25-50% above calculated requirements:

Hot weather adjustment: Australian summers can increase melt loss 30-50% above baseline. Size for summer peak conditions.

Peak period variation: Fish markets may refresh displays at opening, then top up repeatedly. Processing plants may have concentrated production periods.

Equipment cycling: Production rates assume continuous operation. Startup/shutdown cycles reduce effective daily output.

Maintenance windows: Equipment occasionally needs cleaning or service. Buffer capacity covers short maintenance periods.

Unsure about sizing? Get a free sizing consultation →

Installation Requirements for Flake Ice Machines

Electrical Specifications

Machine Class Typical Requirement
Small commercial (200kg) 240V/10-15A single phase
Medium commercial (300-500kg) 240V/15-20A single phase
Large commercial (500-1,000kg) 240V/20A or 3-phase
Industrial (1,000kg+) Three-phase required

Always verify specific model requirements before installation. Electrical infrastructure upgrades may be required for larger systems.

Water Requirements

Pressure: 140-550kPa (20-80 psi) Temperature: 4-32°C inlet water (cooler is better) Quality: Water treatment strongly recommended

Hard water accelerates scale buildup on evaporator drums-the most critical component in flake ice machines. Scale reduces efficiency, degrades ice quality, and shortens equipment life.

Filtration recommendations:

  • Minimum: Sediment filter (5-10 micron) plus carbon block
  • Recommended: Add scale inhibition for TDS >200ppm
  • Best: Reverse osmosis for hard water areas (TDS >400ppm)

The CD40B water filter or CD20B high-capacity filter provides appropriate filtration for most commercial installations. Proper filtration extends equipment life and may be required for warranty coverage.

Drainage Requirements

Flake ice machines produce continuous drainage during operation (unlike batch-harvest cube machines):

  • 50mm minimum drain line
  • Air gap required (prevents backflow contamination)
  • Floor drain within 2 metres preferred
  • Adequate floor drainage capacity for continuous flow
  • Consider drain pump for difficult installations

Ventilation Requirements

Air-cooled units (most commercial):

  • Minimum 150mm clearance on all ventilated sides
  • Ambient temperature below 35°C for rated performance
  • Adequate airflow to dissipate condenser heat
  • Avoid enclosed spaces without ventilation

Water-cooled units:

  • Required for enclosed spaces
  • Required for high ambient environments (>35°C)
  • Common for concrete plant installations
  • Requires cooling water supply and drainage

Floor Load Capacity

Large flake machines with full storage bins create substantial loads:

System Configuration Approximate Weight
300kg machine + 150kg bin (empty) 300-350kg
300kg machine + 150kg bin (full) 450-500kg
500kg machine + 300kg bin (full) 700-850kg
Industrial 1,000kg system 1,200-1,500kg

Verify floor load capacity before installation. Reinforcement may be required for suspended floors.

Maintenance for Flake Ice Machines

Flake machines have unique maintenance requirements centred on the evaporator drum and auger mechanism:

Daily Checks

  • Verify ice quality (dry, consistent flakes-not wet or clumping)
  • Check storage bin fill level
  • Listen for normal operating sounds (auger, compressor)
  • Inspect bin for contamination or debris
  • Verify drain flow during operation

Weekly Maintenance

  • Wipe exterior surfaces
  • Clean ice contact surfaces accessible without disassembly
  • Check water inlet filter
  • Inspect bin interior for scale buildup
  • Verify normal temperature readings if equipped

Fortnightly Maintenance

  • Clean ice contact surfaces thoroughly
  • Check auger/scraper condition (visual inspection)
  • Inspect condenser coils for dust/debris (air-cooled)
  • Verify refrigerant pressures if gauges accessible
  • Clean drip trays and drain paths

Monthly Maintenance

  • Full bin sanitisation with manufacturer-approved solution
  • Clean condenser coils (air-cooled)
  • Check refrigerant pressures (professional recommended)
  • Inspect auger for wear patterns
  • Verify all safety switches function

Quarterly Maintenance

  • Deep descale evaporator drum (professional service recommended)
  • Replace water filters
  • Professional inspection and service
  • Lubricate bearings if specified by manufacturer
  • Check electrical connections and controls

Annual Maintenance

  • Comprehensive professional service
  • Full refrigerant system inspection
  • Replace worn auger/scraper components as needed
  • Inspect evaporator drum for wear or corrosion
  • Full system calibration and testing

Lifespan Expectations

Industry experience suggests flake ice machines may deliver:

  • Quality commercial equipment (Grant, Ice-O-Matic, Follett): Average 7-10 years under normal conditions, 10-15+ years with excellent maintenance
  • Industrial systems: 10-15 years average, 12-20+ years with exceptional maintenance depending on duty cycle

Actual lifespan varies significantly based on usage intensity, maintenance quality, water conditions, and operating environment.

Common wear points:

  • Auger/scraper: Replace every 5-8 years in high-volume operations
  • Evaporator drum: May need replacement after 10-15 years
  • Bearings: Variable depending on design and conditions
  • Compressor: 10-15 years typical for commercial compressors

Budget for component replacement in total cost of ownership calculations.

Cost Analysis: Flake Ice Machine Economics

Purchase Price Ranges

Category Price Range (AUD)
Hospitality/light commercial (200kg/day) $7,000-10,000
Medium commercial (300kg/day) $9,000-14,000
High-volume commercial (500kg+/day) $14,000-20,000
Industrial (1,000kg+/day) $20,000-40,000+
Hoshizaki FM series $18,000-28,000
Scotsman AF/Prodigy series $15,000-25,000

Operating Costs (Projected Estimates)

The following are industry estimates-actual costs vary by energy rates, water quality, usage, and local conditions.

Energy consumption:

  • Small commercial: ~$30-50/month
  • Medium commercial: ~$60-100/month
  • Large commercial: ~$120-200/month
  • Industrial: ~$300-600/month

Water consumption:

  • Flake ice uses water efficiently (minimal waste)
  • Cost approximately equals municipal water rates × ice production

Maintenance:

  • Filter replacement: ~$50-150/quarter
  • Professional service: ~$200-400/service
  • Annual budget: ~$800-1,500 for medium commercial

Total Cost of Ownership (10-Year Projected Estimates)

Equipment pricing is indicative and subject to change. Contact Coast Distributors for current pricing. These are illustrative projections based on industry benchmarks. Actual costs vary by usage, energy rates, water quality, and maintenance practices.

Machine Category Purchase Energy Water Maintenance Total TCO
Hospitality (200kg/day) ~$8,000 (indicative) ~$5,000 ~$2,500 ~$10,000 ~$25,500
Medium commercial (300kg/day) ~$12,000 (indicative) ~$8,000 ~$4,000 ~$12,000 ~$36,000
High-volume (500kg/day) ~$16,000 (indicative) ~$15,000 ~$6,000 ~$15,000 ~$52,000
Hoshizaki FM-480AKE (425kg/day) ~$22,000 (indicative) ~$10,000 ~$5,000 ~$8,000 ~$45,000

Want accurate pricing for your specific needs? Request a detailed quote →

Warranty Comparison

Brand Standard Warranty Extended Coverage
Grant Sub Zero 3 years parts & labour 5 years evaporator
Ice-O-Matic MFI 3 years parts & labour 5 years compressor
Follett MFE 3 years parts & labour 5 years compressor
Hoshizaki FM 2 years parts & labour 5 years compressor & condenser (parts only)

Warranty terms vary by distributor and region. Coast Distributors provides full parts and labour coverage on Grant, Ice-O-Matic, and Follett products.

Common Questions About Flake Ice Machines

How cold is flake ice? Quality flake ice is subcooled to approximately -7°C to -5°C, significantly colder than cube ice at 0°C. This subcooling provides additional cooling capacity and longer storage life.

Why does my flake ice clump together? Clumping indicates either wet flake (machine issue requiring service) or storage too long without agitation. Quality machines produce dry flake that resists clumping. Storage bins may need periodic raking during extended storage.

Can I use flake ice for drinks? Not recommended. Flake ice melts rapidly and over-dilutes beverages. Use cube or nugget ice for drink service.

How fast do flake ice machines produce ice? Faster than cube makers per kg-flake machines produce continuously rather than in batch cycles. A 300kg/day machine produces approximately 12.5kg per hour continuously.

What water quality do flake machines need? Moderate to good. Hard water accelerates scale on evaporator drums, reducing efficiency and shortening lifespan. Filtration extends machine life significantly and should be considered mandatory for commercial installations.

How do I know if I need flake or cube ice?

  • Flake for: Food display, seafood, product cooling, medical applications, concrete, food processing
  • Cube for: Beverages, self-serve, general commercial
  • If product presentation or rapid cooling is primary requirement, choose flake.

What's the difference between flake and nugget ice? Both use auger production, but nugget ice compresses flakes into soft, chewable pellets. Flake ice remains loose, thin fragments. Flake excels at food display; nugget excels at beverages and healthcare patient consumption.

How long do flake ice machines last? Quality commercial equipment (Grant Sub Zero, Ice-O-Matic, Follett): Average 7-10 years under normal conditions, 10-15+ years with excellent maintenance. Industrial equipment: 10-15 years average, 12-20+ years with exceptional maintenance depending on duty cycle.

Can I convert a flake machine to make nugget ice? Most flake ice machines are single-purpose and cannot convert. If you need both flake and nugget ice, consider separate machines for each application to ensure optimal performance.

Our Recommendations by Application

Best self-contained for seafood: Grant Sub Zero PB0.3F-FZ/Y-300kg daily with 150kg integrated storage, dry subcooled flake quality, Australian climate engineering.

Best modular for flexible installations: Grant MB0.3F-FZ/Y-same quality as self-contained with bin flexibility for custom requirements.

Best for hospitality and healthcare: Follett MFE414ABT-193kg daily with Maestro platform efficiency, quiet operation, and healthcare-appropriate design.

Best mid-range commercial: Ice-O-Matic MFI0805A-333kg daily with extended warranty coverage and proven Ice-O-Matic reliability.

Best high-volume commercial: Ice-O-Matic MFI1255A-572kg daily for large fish markets, processing facilities, and high-volume operations.

Best industrial (with refrigeration): Grant FF-AR series-FF1AR (1,000kg) through FF10AS (10,000kg) for large-scale operations.

Best industrial evaporator: Staff SPS950 through SPS3000-950kg to 3,000kg daily for facilities with existing refrigeration.

Hoshizaki FM-480AKE/FM-600AKE: Premium Japanese engineering with strong build quality. Available through Hoshizaki distributors-contact them directly for local service and parts support.

Get Expert Help Choosing Your Flake Ice Machine

Coast Distributors makes it easy to find the perfect flake ice machine for your operation:

? Call Us: 1800 688 590 (Freecall)
✉️ Email: sales@coastdistributors.com.au
? Locations: Sydney, Melbourne, Perth

Quick Actions:

Why Choose Coast Distributors?

  • Exclusive Australian Importer - Grant Sub Zero, Ice-O-Matic, Follett, Staff
  • 80+ Years Experience - Australia's largest commercial ice equipment distributor
  • Full Technical Support - From sizing to installation to ongoing maintenance
  • Nationwide Service - Sydney, Melbourne, Perth locations
  • Genuine Parts & Warranty - Full manufacturer support

Explore our flake ice machine range:

For cube ice applications, see our modular cube ice makers or undercounter ice machines. For healthcare and hospitality nugget ice, explore our chewblet ice machines.

Ready to get started? Contact us today →

Coast Parts
